| Product Type | Controller |
| Length (mm) | 86 |
| Width (mm) | 86 |
| Height (mm) | 50 |
| Housing Color | White |
| Housing Material | PC |
| Mounting | Built-in |
| Weight (g) | 220 |
| CE | √ |
Electronics
| Input Domain | AC |
| Input Voltage | 100 ~ 240V AC |
| Power Supply | Internal |
| LED Outputs | 1 |
| Input Frequency | 50 ~ 60Hz |
Lighting
| Color Range | Single Color |
Control
| Signal | 1~10V |
| Control | 0-10V |
| Number of Channels | 1 |
Environmental
| Operating Temperature | -10 ~ +50 °C |
| IP Rating | IP20 |
| Environment | Indoor |
Other
| Country of Origin | People's Republic of China |
| HS Code | 8537109899 |
Approvals
| RoHS | √ |
| Certification | CE |
Warranty
| Warranty | 5 Year |
EU Declaration of Conformity
| 2011/65/EU Restriction of Hazardous Substances Directive (RoHS) + 2015/863/EU | √ |
| 2014/35/EU Low Voltage Directive (LDV) | EN 61347-1 |
| 2014/35/EU Low Voltage Directive (LDV) | EN 61347-2-13 |
| 2014/53/EU Radio Equipment Directive (RED) | ETSI EN 301 489 |
| 2014/53/EU Radio Equipment Directive (RED) | ETSI EN 300 328 |
| 2014/53/EU Radio Equipment Directive (RED) | EN 60950-1 |
-
| ETIM Classification | EC002924 Controller for luminaires |
